Quick guide
420-84
Power Station
AC 300
Quick guide
Overview
1. Cooling fan
2. DC Input
3. Power button
4. Digital Display Screen
5. AC Power button
6. AC Output
7. USB 1 Output
8. USB QC3.0 Output
9. USB 2 Output
10. DC 1 Output
11. USB-C Input/Output
12. DC 2 Output
13. LED light button
14. Lamp
2
1
6
7
10
9
8
3 5
4
13
14
2
1211
Not permitted on aircrafts.
Avoid rain and liquids.
Quick guide
Detailed specification
3
AC EU wall
socket:
230V AC, 50
Hz (300W
max)
USB-A 1
Output:
5V/2.1A
USB-A 2
Output:
5V/2.1A
USB QC3.0
Output:
QC 5V/3A,
9V/2A,
12V/1.5A
(18W max)
USB-C PD
Input/Output:
5V/2.4A,
9V/3A, 12V/3A,
15V/3A,
20V/5A (100W
max)
DC port
(5521)
Output:
12V/10A
(120W max)
DC port
(5521)
Output:
12V/10A
(120W max)
DC port
(5521) Input:
5V-20V/5A
(100W max)
98%
98%
DC/PD Input
Solar Panel
Charger Wall Charger
Quick guide
Charge the powerbank
Button function
4
USB-C PD Input
DC port
(5521) Input:
5V-20V/5A
(100W max)
INPUT DC
98%
98%Check the battery capacity
Press and hold
power button for 5 seconds to turn on/off the device
Press power button to turn on the DC Output
98%
OUTPUT DC
Press power button to turn off the DC Output
Press and hold AC power button for 5 seconds to turn on the AC Output Press and hold AC power button for
5 seconds to turn off the AC Output
98%
OUTPUT AC
Quick guide
Charge mobile device (USB 2 Output, USB QC3.0 Output and USB-C Output)
5
Example of use
98%
Quick guide
Charge equipment (AC Output)
6
Example of use
Press and hold power button for 5 seconds to turn on the device
Press and hold AC power button for 5 seconds to turn on the AC Output
21
Quick guide
Lamp
7
21
Press and hold power button for 5 seconds to turn on the device
Press and hold LED light button for 5 seconds
3
Press once more
4
Press once more
5
Press once more
6
Press once more
7
Press once more
Warranty
There is a five-year warranty on your Sandberg product.
Please read the warranty terms and register your new Sandberg product at https://www.sandberg.world/warranty
https://helpdesk.sandberg.world
Helpdesk
Years
Warranty
For information on handling electronic waste, see https://www.sandberg.world/weee
8
Li-ion Battery capacity: 14.4V/20Ah/288Wh (3.6V/80000mAh/288Wh)
1 x AC EU-wall socket: 230V AC, 50 Hz (300W max)
1 x DC-port (5521) input: 5V-20V/5A (100W max)
2 x DC-port (5521) output: 12V/10A (120W max)
2 x USB-A output: 5V/2.1A
1 x USB-A output: QC 5V/3A, 9V/2A, 12V/1.5A (18W max)
1 x USB-C PD in/out: 5V/2.4A, 9V/3A, 12V/3A, 15V/3A,
20V/5A (100W max)
Made in China
Sandberg A/S
Bregneroedvej 133D,
3460 Birkeroed, Denmark
www.sandberg.world
Item no. 420-84
Power Station AC 300
Product weight: 2900g
[email protected]
NOTE: For optimal battery performance, we recommend fully discharging and recharging the powerbank at least once every three months.
