Quick guide
421-13
Laptop
Powerbank
27000 PD100W
www.sandberg.world
Quick guide
Overview
1. DC Input
2. LED display
3. USB-C 1 Input/Output
4. USB-A Output
5. USB-C 2 Output
6. Power button
7. DC Output
8. Laptop Voltage button
9. Wireless charging Area
2
1 2 3 4 5
6
9
7
8
Quick guide
3
DC/PD Input
Solar Panel
Charger Wall Charger
Charge the powerbank
USB-C Input: PD
DC Input: 12-24V/3A (72W max)
Display indicating the charged capacity of the battery.
Press once to check the capacity status
Quick guide
Charge mobile device (USB-A and USB-C 2 Output)
USB-A
USB-C
4
Quick guide
Charge laptop (DC or USB-C 1 Output)
5
Select correct Laptop DC connector
Quick guide
Charging a laptop with DC cable - important note
1. Choose correct tip to fit the DC port of your laptop.
2. Set the correct voltage on the power bank:
Keep long press on the Laptop Voltage button until display is flashing.
Click Laptop Voltage button short to step between Voltage 12V/16.5V/20V/24V.
3. Connect the laptop, charge will start.
4. After disconnecting the laptop, you need to set the Voltage next time.
For safety it will always start the cycle at lowest setting 12V.
NOTE: If you are in doubt on what DC-Voltage to choose, have a look at the label on the AC charger for the laptop.
12V
16.5V
20V
24V
6
Flashing
Quick guide
Wireless charger
7
Warranty
There is a five-year warranty on your Sandberg product.
Please read the warranty terms and register your new Sandberg product at https://www.sandberg.world/warranty
https://helpdesk.sandberg.world
Helpdesk
Years
Warranty
For information on handling electronic waste, see https://www.sandberg.world/weee
8
NOTE: For optimal battery performance, we recommend fully discharging and recharging the powerbank at least once every three months.
Item no. 421-13
Battery capacity: 27000 mAh / 99.9 Wh / 3.7V
Battery pack capacity: 22.2V/4500 mAh/99.9 Wh
DC-port input: 12-24V/3A (72W max)
DC-port output: 12V/5A, 16.5V/4A, 20V/3.5A, 24V/3.5A (84W max)
USB-C PD input: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A (60W max)
USB-C PD output: 5V/3A, 9V/3A, 12V/3A,15V/3A, 20V/5A (100W max)
USB-A output: 4.5V/5A, 5V/4.5A, 9V/2A, 12V/1.5A (22.5W max)
USB-C (2) output: 5V/3A, 9V/3A, 12V/2.5A (30W max)
Wireless charger max: 10W
Sandberg A/S
Bregneroedvej 133D,
3460 Birkeroed, Denmark
www.sandberg.world
Laptop Powerbank 27000 PD100W
Product weight: 589g
Made in China
PLEASE READ
This battery stays on in DC mode to ensure constant power.
When not in use, hold the power button for 3 seconds to turn it off.
If left on, the battery may slowly drain. Then recharge it when needed.
